EQUIPMENT 主要設備 EQUIPMENT 主要設備

加工設備※全ての設備および設備の詳細情報は公開していません

FACILITY NAMEMANUFACTURER
Super Precision Micro Machining Center MEGA SSS-400Roku-Roku Sangyo
High-Precision Micro Fine Machining Center CEGA SS-300Roku-Roku Sangyo
High-Precision Micro Fine Machining Center CEGA SS-400 ※4AXES Roku-Roku Sangyo
Ultra-Precision Micro Fine Machining Center Android Ⅱ type SRoku-Roku Sangyo
ROBO DRILLFANUC
CNC Lathes QUICK TURN 200ⅡYamazaki Mazak
CNC Lathes QUICK TURN 250MYYamazaki Mazak
CNC GEAR Hobbing MachineHAMAI SANGYO
Mechanical Engraving-
Panel Saw MachineSHINX
Polishing Machine-
Ultra Lapping Machine #3000NSS co., ltd *Jp3 special model
Ultra Lapping Machine #5000 *Jp3 original virsionNSS co., ltd *Jp3 special model
Ultra Lapping Machine #10000 *Jp3 original virsionNSS co., ltd *Jp3 special model
Ultra Lapping Machine #20000NSS co., ltd *Jp3 special model
Dry ice powder shotting MachineNIHON EKITAN
Ultra Sonic Plastic Welder-
Injection Molding Machine 50TTOYO
Injection Molding Machine 80TNISSEI
Injection Molding Machine 110TNIHONSEIKO / NISSEI
Injection Molding Machine 160TNIIGATA

検査機器

FACILITY NAMEMANUFACTURER
3D Laser Scanning Confocal Microscope *VK-X seriesKEYENCE
3D Scanner 3D-Measuring Microscope *VL seriesKEYENCE
Handheld Probe 3D-Measuring Machine *XM-T1200/1500KEYENCE
Wide-Area 3D Measurement System *VR-3200KEYENCE
3D Measuring MicroscopeFARO GAGE
CNC Vision Measuring System *Quick Vision HYPER ProMitutoyo
Digital Microscope *VHX-6000 seriesKEYENCE
Digital Microscope *VHX-7000 seriesKEYENCE
Automatic Optical & Measuring MicroscopeVision Engineering
3D Visual Inspection MicroscopeVision Engineering
Rectangular Lens LED Bench MagnifierVision Engineering
High-precision Image Dimension Measurement System *LM seriesKEYENCE
Image Dimension Measurement System *IM-6225KEYENCE
Image Dimension Measurement System *IM-7500KEYENCE
Hight Dimension Measurement System *HM-1000 seriesKEYENCE
High-resolution Digital Measuring Unit *LITEMATIC VL-50S ※Low and constant measuring force of 0.01 N, 0.15 NMitutoyo
Digital Force Gauge *ZTS-DPU-20NIMAI
GEAR Rolling Tester *GTR-4LsOSAKA SEIMITSU
CNC Automatic GEAR Measuring System *TTi-120HTOKYO TECHINICAL
MASTER GEAR-1  ※Module: 0.3 / 0.35 / 0.4 / 0.5 / 0.6 / 0.65 / 0.7 / 0.75 / 0.8 / 1.0OSAKA SEIMITSU
Digital Vernier Caliper ※Measurement Range: 0-150 mm / 0-200 mm / 0-300 mm / 0-600 mmMitutoyo
CR Vernier CaliperToueikougyo
Micrometer ※Measurement Range: 0-25 mm / 25-50 mm / 50-75 mm / 75-100 mmMitutoyo
Blade Micrometer ※Measurement Range: 0-25 mm / 25-50 mmMitutoyo
Inside Micrometer ※Measurement Range Range: 5-25 mm / 25-50 mmMitutoyo
GEAR Tooth Micrometer ※Measurement Range: 5-25 mmMitutoyo
Test IndicatorMitutoyo
Dial Gauge-1 *Minimum scale: 0.01 mmMitutoyo
Dial Gauge-2 *Minimum scale: 0.001 mmMitutoyo
Block Gauge Set *1.00, 1.01-1.09, 1.1-1.9, 1-9, 10, 20, 25, 30, 50Mitutoyo
Pin Gauge Set *φ 0.50-10.00 (every 0.01)AIZEN
Pin Gauge Set *φ 9.8-12.525 (every 0.025)AIZEN

※2022年 4月末 現在

*Current as of Apr 2022
